DC DC Charger Victron Orion-Tr Smart 12/12 30A Non-Isolated

Advanced Features of the 12v DC-DC Charger Bluetooth Enabled Victron Orion-Tr Smart

The Orion-Tr Smart DC-DC charger is a professional DC to DC adaptive 3-stage charger with built-in Bluetooth.

For use in dual battery systems in vehicles or on boats where the (smart) alternator and the start battery are used to charge the service battery. The unit can be monitored and programmed via Bluetooth and can be remotely controlled via a remote on/off switch and has an engine running detection mechanism.

The Orion Tr-Smart charger can be used in 12V or 24V systems and is suitable for both lead acid and lithium batteries. Models are available up to 400W and unlimited multiple units can be connected in parallel to increase output power.

Suitable for high temperatures up to 55°C with a full rated output up to 40°C.

Features

Bluetooth Smart enabled

Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available.

Fully programmable

Battery charge algorithm (configurable) or fixed output.

Smart alternator compatibility: engine running detection mechanism.

Adaptive 3-stage charge algorithm: bulk – absorption – float

For lead acid batteries it is important that during shallow discharges the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure that the battery is completely recharged.

For lithium batteries absorption time is fixed, default 2 hours.

Alternatively, a fixed output voltage can be chosen.

Remote on-off

A remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example).

All models are short circuit proof and can be paralleled to increase output current

An unlimited number of units can be connected in parallel.

High temperature protected

The output current will reduce at high ambient temperature.

IP43 protection

When installed with the screw terminals oriented downwards.

Screw terminals

No special tools needed for installation.

Input fuse (not replaceable)



Bluetooth Connectivity for Smart Monitoring





The Victron Orion-Tr Smart 12/12 30A non-isolated DC-DC charger is equipped with Bluetooth functionality, enabling seamless wireless communication. This 12v dc-dc charger bluetooth setup allows users to easily monitor and configure the charging process via a smartphone or tablet. With Victron’s dedicated app, you get real-time data on battery status, charge settings, and performance metrics. This smart feature provides enhanced user experience and precise control over battery management, making it a top choice for professionals and enthusiasts alike.





Non-Isolated DC-DC Charging Technology





This 12v dc-dc charger bluetooth model utilizes a non-isolated topology, which delivers efficient power transfer and compact design. Non-isolated chargers are ideal for vehicles and dual battery systems where weight and size are critical considerations. The Victron Orion-Tr Smart ensures a stable 30A output capable of charging different 12V battery chemistries reliably while minimizing energy loss. Its advanced circuitry safeguards batteries from overcharging and extends their lifespan.





Robust Build and Versatile Applications





Designed for durability and versatile use, the Victron Orion-Tr Smart 12/12 30A charger suits various applications ranging from automotive to marine and off-grid solar setups. The Bluetooth-enabled charger supports intelligent charge algorithms compatible with lead-acid, lithium, and other battery types. Its rugged construction withstands harsh environments, while built-in protection mechanisms prevent damage from voltage spikes or overheating. This blend of smart technology and reliability makes it a valuable addition to any battery system requiring efficient and safe DC-DC conversion.
